Inline Vertical Curing Oven
Vertical heating oven with up to 12 heating modules and ±2°C temperature uniformity for curing and pre-heating processes in SMT production.
Product Overview
The Vanstron Inline Vertical Curing Oven provides precise, uniform heating for curing and pre-heating processes in SMT production lines. The vertical design maximizes floor space utilization while offering up to 12 individually controlled heating modules for precise temperature profiling.
Available in two models: the VBH-250 supports temperatures up to 200°C for high-temperature curing applications, while the VBH-90 is optimized for lower-temperature processes up to 90°C. Both models deliver ±2°C temperature uniformity across the heating chamber.
The oven integrates into existing SMT lines via SMEMA and IPC Hermes 9852 communication interfaces, enabling automated temperature profile management and real-time production monitoring in Industry 4.0 environments.
Key Features
- Up to 12 individually controlled heating modules
- ±2°C temperature uniformity across the heating chamber
- Two models: VBH-250 (up to 200°C) and VBH-90 (up to 90°C)
- Vertical design for minimal floor space usage
- Programmable temperature profiles with recipe management
- Closed-loop PID temperature control
- Integrated cooling zone for controlled board exit temperature
- SMEMA and IPC Hermes 9852 communication interfaces
- Touch-screen HMI for profile setup and monitoring
- Energy-efficient insulation design
Technical Specifications
| Parameter | VBH-250 | VBH-90 |
|---|---|---|
| Max Temperature | 200°C | 90°C |
| Temperature Uniformity | ±2°C | |
| Heating Modules | Up to 12 | |
| Temperature Control | Closed-loop PID | |
| Communication | SMEMA, IPC Hermes 9852 | |
| Industry Standard | Industry 4.0 Ready | |
